| Place of Origin: | China |
|---|---|
| ชื่อแบรนด์: | Topcon |
| Model Number: | ES602G |
| Minimum Order Quantity: | 1pc |
| Packaging Details: | with plastic case inner and the carton outer |
| Delivery Time: | within 3-5days after the goods are paid. |
| Payment Terms: | TT |
| Supply Ability: | 10000 Per Year |
| เน้น: | reflectorless total station,manual total station |
||
|---|---|---|---|
|
ES-600G Technic Data
|
|||||
| Model | ES-602G | ES-605G | |||
| Telescope | |||||
| Magnification /Resolution | 30X/2.5" | ||||
| Others | Length of Lens: 171mm,Objective Aperture :45mm(EDM:48mm),Erect, Field Of View: 1˚30′(26m/1,000m),Minimum Focus: 1.3m, Back light:5 Class | ||||
| Angle Measurements | |||||
| Minimum Reading | 1"/5" | ||||
| Angle Measurements Accuracy (ISO17123-3:2001) | 2" | 5" | |||
| Dual Axis Compensator/Collimation Error Correction |
Liquid twin screw tilt sensor ,Compensator Range ±6′/Collimator Correction |
||||
| Measuring Distance Part | |||||
| Laser output grade | Non prism:3R grade ,prism /reflctor sheet 1 grade | ||||
| Measuring Range (the general weather condition ) |
Non prism | 0.3～500m | |||
| Reflector Sheet | RS90N-K:1.3～500m；RS50N-K:1.3～300m；RS10N-K:1.3～100m | ||||
| Mini Prism | 1.3～500m | ||||
| Single Prism | 1.3～4,000m/ good weather condition *6:1.3～5,000m | ||||
| Mini Display | Fine Measuring/Rapid Measuring:0.001m Tracking:0.01m | ||||
| Distance Measuring Accuracy (ISO17123-4:2001) |
Non Prism | (3+2ppm×D)mm*7 | |||
| Reflector Sheet | (3+2ppm×D)mm | ||||
| Prism | (2+2ppm×D)mm | ||||
| Measuring Time | Fine:0.9s,Rapid :0.7,Tracking:0.3s | ||||
| Port and Data Management | |||||
| Display/ Key Board | Adjective Contrast Ratio ,with backlight 192×80point ,Dot Matrix LCDS graphic display / with backlight 25 key ( Alphabet Number keyboard) . | ||||
| Operating Panel | Double Side | ||||
| Trigger Key | On the right side of instrument, A key Trigger | ||||
| Data memory | Internal Memory | About 10,000 points | |||
| External Memory | USB flash Memory (Max. 8GB) | ||||
| Port | RS-232C serial port,USB2.0(A port,to use connect with U display) | ||||
| Bluetooth Model (optional) | 1 Grade Bluetooth, Ver.2.1 +EDR,Transfer Distance:300m*10 | ||||
| Others | |||||
| Laser Alignment | Coaxial red EDM laser beam | ||||
| Guid light | Green Laser Diode(524nm)and red laser Diode(626nm),Work Rang: 1.3～150m | ||||
| Spirit Level | Electronic Spirit Level | 6′(inner circle ) | |||
| Circle Spirit Level | 10′/2mm | ||||
| Laser Plummet ( Optional) | 2 Grade laser products, Red laser Diode (635nm±10nm),Plummet Accuracy: ≦1.0mm/1.3m | ||||
| Optics Plummet | Magnification:3X,Minimus Focus: 0.3m(From Tribrach) | ||||
| Dustproof and Waterproof | IP66(ICE 60529:2001) | ||||
| Work Temperature | -20～+60℃ | ||||
| Size(including handle) | 191mm(W)×181mm(L)×348mm(H) | ||||
| Weight (including Handle and Battery) | 5.6kg | ||||
| Power System | |||||
| Battery | BT-L2 On Board Battery | Recharger Battery | |||
| Work Time | About 25 Hours ( the different between the angle measuring and distance measuring 1 time /30s) | ||||
